Laiton |
Inox |
Aluminium |
DN |
Pour tuyau |
Plage de serrage |
Visserie |
YSDCLT013005 |
YSDCIX013005 |
YSDCAL013005 |
13 |
13*5 |
22-24 |
M6 |
YSDCLT019006 |
YSDCIX019006 |
YSDCAL019006 |
19 |
19*6 |
30-33 |
M6 |
YSDCAL025005 |
25 |
25*5 |
34-36 |
M6 |
||
YSDCLT025006 |
YSDCIX025006 |
YSDCAL025006 |
25 |
25*6 |
36-39 |
M6 |
YSDCAL025008 |
25 |
25*8 |
40-43 |
M6 |
||
YSDCAL032005 |
32 |
32*5 |
41-43 |
M6 |
||
YSDCLT032006 |
YSDCIX032006 |
YSDCAL032006 |
32 |
32*6 |
43-46 |
M6 |
YSDCAL032008 |
32 |
32*8 |
53-56 |
M6 |
||
YSDCAL038005 |
32 |
32*5 |
47-49 |
M6 |
||
YSDCLT03806.5 |
YSDCIX03806.5 |
YSDCAL03806.5 |
38 |
38*6,5 |
50-53 |
M6 |
YSDCAL038008 |
38 |
38*8 |
53-56 |
M6 |
||
YSDCAL038010 |
38 |
38*10 |
57-60 |
M7 |
||
YSDCAL040007 |
40 |
40*7 |
53-56 |
M6 |
||
YSDCAL040010 |
40 |
40*10 |
58-61 |
M6 |
||
YSDCAL045007 |
45 |
45*7 |
58-61 |
M6 |
||
YSDCAL050002 |
50 |
50*2 |
52-54 |
M6 |
||
YSDCAL050006 |
50 |
50*6 |
61-63 |
M6 |
||
YSDCLT050008 |
YSDCIX050008 |
YSDCAL050008 |
50 |
50*8 |
63-67 |
M8 |
YSDCIX050010 |
YSDCAL050010 |
50 |
50*10 |
69-71 |
M8 |
|
YSDCAL063006 |
65 |
63*6 |
74-76 |
M8 |
||
YSDCLT065007 |
YSDCIX065007 |
YSDCAL065007 |
65 |
65*7 / 63*8 |
78-82 |
M8 |
YSDCAL063010 |
65 |
63*10 |
84-87 |
M8 |
||
YSDCAL075006 |
75 |
75*6 |
84-86 |
M8 |
||
YSDCLT075008 |
YSDCIX075008 |
YSDCAL075008 |
75 |
75*8 |
89-93 |
M8 |
YSDCAL075010 |
75 |
75*10 |
94-97 |
M8 |
||
YSDCAL075012 |
75 |
75*12 |
98-101 |
M8 |
||
YSDCIX080008 |
YSDCAL080008 |
80 |
80*8 |
94-97 |
M8 |
|
YSDCAL080010 |
80 |
80*10 |
99-102 |
M8 |
||
YSDCAL090005 |
90 |
90*6,5 |
104-108 |
M8 |
||
YSDCAL100006 |
100 |
100*6 |
111-115 |
M10 |
||
YSDCLT100008 |
YSDCIX100008 |
YSDCAL100008 |
100 |
100*8 |
114-119 |
M10 |
YSDCAL100010 |
100 |
100*10 |
118-122 |
M10 |
||
YSDCAL100012 |
100 |
100*12 |
122-126 |
M10 |
||
YSDCAL125010 |
125 |
125*10 |
143-148 |
M10 |
||
YSDCAL125013 |
125 |
125*13 |
149-154 |
M10 |
||
YSDCAL150010 |
150 |
150*10 |
178-184 |
M12 |
||
YSDCAL150013 |
150 |
150*13 |
174-180 |
M12 |
||
YSDCAL200012 |
200 |
200*12 |
222-229 |
M12 |
||
YSDCAL200016 |
200 |
200*16 |
230-239 |
M12 |
Normes | EN 14420-3 / DIN 2817 |
---|
